Je bekijkt pagina 45 van 55
Electronic manometer PG17xx
45
10.5.4.1 Parameter setting via unit keys: display brightness
u Call up the menu [EF] > [DIS].
u Select [diS.B] and set the brightness of the display.
10.5.5 Display update rate
The update rate of the display can be set via the parameter [diS.U].
Selectable values:
• d1: fast
• d2: medium
• d3: slow
10.5.5.1 Parameter setting via unit keys: display update rate
u Call up the menu [EF] > [DIS].
u Select [diS.U] and set the update rate.
10.5.6 Status LED
The status LED can be set via [LEd.m].
Selectable values:
• [On]: The status LED is permanently on. Green in normal operation, yellow in the event of a
warning, red in the event of a fault.
• [OFF]: The status LED is permanently off.
• [NoTI]: The status LED only lights or flashes red in the event of a warning or error.
10.5.6.1 Parameter setting via the device keys: Status LED
u Call up the menu [EF] > [DIS].
u Select [LEd.m] and set status LED.
10.5.7 Dynamic LED pointer
If the pressure changes rapidly, the LED pointer will fan out between the minimum and maximum
values in the current process value display. The main pointer will show the average value.
The dynamic LED pointer is independent of the lag indicator LEDs which indicate minimum and
maximum pressure values in the LED ring (Ò Display layout/42).
The parameter [P.VEL] is used to set the velocity the main pointer must have during dynamic process
fluctuations for the dynamic LED pointers to become visible.
