MFH2xx Pressure-resistant position sensor for hydraulic cylinders
18 © ifm electronic gmbh 11660562 / 00 06 / 2025
SSC1.x Delay. Select Switching delay and set the time for the switching delay.
SSC1.x Delay. Select Reset delay and set the time for the reset delay.
10.6 Teach functions
The teach functions can be used to teach switch points for the switching channels SSC1.1 and SSC1.2
based on the current target position.
10.6.1 Switch point teach
In case of the switch point teach Teach SPx, the switch points are taught individually for the selected
switching channel SSC1.x on the basis of the current target position. The mode can be freely selected.
In Single Point mode, the current measured value plus the set hysteresis is adopted as switch point SP1,
so that the switch point has a reserve when the piston is fully in the end position:
• SP1 = current measured value + hysteresis
9
In the Window mode and in the Two Point mode, the switch point SPx is set exactly to the current meas-
ured value:
• SP1 = current measured value
• SP2 = current measured value
Keep the measured value
PDV1
constant during the teach process to ensure a safe switch
point.
The switch points can also be set manually without a teach command.
Parameter setting:
Install the device in the cylinder.
Select Parameter > SSC1.x.
Single point mode:
Select SSC1.x Config.Mode and set the Single Point mode.
Select SSC1.x Config.Hyst and set the hysteresis.
Move the piston to the desired position for switch point 1.
Ensure that the current measured value is within the limits of the measuring range.
Select Parameter > Teach.
Select Teach Select and set the switching output SSC1.x.
Save the changed parameter settings on the device.
Execute the command: Teach SP1.
The current value plus hysteresis is adopted as switch point SP1.
Teach Result. State shows the status of the teach process.
The switch point SP1 is set for the selected switching channel.
Window and Two Point Mode:
Select SSC1.x Config.Mode and set the mode: Two Point or Window.
Move the piston to the desired position for switch point 1.
Ensure that the current measured value is within the limits of the measuring range.
