Evaluation unit for monitoring and converting frequency signals DW3003
29
9.3.6 Display settings
Menu Description
[diS.U] [diS.U] Refresh rate of the device display.
[d1] [d1] Fast refresh rate.
[d2] [d2] Medium refresh rate.
[d3] [d3] Slow refresh rate.
[Loc] - This lock prevents the settings from being changed via the local operat-
ing elements on the device.
[Loc] can be reset on the device.
See also Locking / unlocking (Ò/22).
[Loc] - Local control element is locked. The device settings cannot be
changed via the local control element.
[uLoc] - Local control element is unlocked. The device settings can be changed
via the local control element.
[Device access locks.lo-
cal parameterization]
- This lock prevents the settings from being changed via the local operat-
ing elements on the device.
[S.Loc] cannot be reset on the device.
See also Locking / unlocking (Ò/22).
[Locked] - Local control element is locked. The device settings cannot be
changed via the local control element.
[Unlocked] - Local control element is unlocked. The device settings can be changed
via the local control element.
9.3.7 Diagnostics
Menu Description
[Operating hours] - Only counts full operating hours. Operating times of less than one full
hour are not saved. Counter values are saved permanently.
[Internal temperature] - Reads the data from the internal temperature sensor of the microcon-
troller.
9.3.8 Identification
Menu Description
[Application-Specific Tag] - Customer-specific application description, max. 32 ASCII characters
long.
[Function Tag] - Customer-specific application description, max. 32 ASCII characters
long.
[Location Tag] - Customer-specific application description, max. 32 ASCII characters
long.
[Product URI] - Represents a unique instance identification according to DIN-SPEC
91406, max. 100 characters. The value is device-dependent and can-
not be changed.
9.4 System commands
Menu Description
[Teach SP1]
[Teach SP2]
[tSP1]
[tSP2]
Adopts the current process data value for SP1 or SP2 of the selected
SSC switching channel.
See Configuration of the switching outputs
