Remote I/O module 8DO 8DI AL4322
27
Name Description Value range Access
[debounce_time] Pin 2: debounce time (= value *
0.1ms)
• 0: 0ms (default)
…
• 500: 50 ms
rw
1
[hold_time] Pin 2: hold time (= value * 0.1ms) • 0: 0ms (default)
…
• 60000: 6000 ms
rw
1
[hold_level] Pin 2: hold level • 0: hold LOW
• 1: hold HIGH (default)
rw
1
[invert] Pin 2: inversion • 0: do not invert (default)
• 1: invert
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
u Select menu [io] > [port[n]] > [pin2] (n: 5...8).
w The menu page shows the available filter parameters for pin 2 of the port.
u Set the parameters.
u Select menu [io] > [port[n]] > [pin4] (n: 5...8).
w The menu page shows the available filter parameters for pin 4 of the port.
u Set the parameters.
u Write the changed values to the device.
w The digital input filters have been configured.
9.1.6 Ports: Reading digital input data
Available information:
Name Description Value range Access
[digital] Signal level of the digital input chan-
nel (after filtering)
• LOW: off
• HIGH: on
ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w In substructure io/port[n] (n: X5...X8), the present signal levels of the digital outputs on pin 2
and pin 4 are displayed.
The displayed signal levels are the filtered input data.
9.1.7 Ports: configuring the outputs
Available parameters:
Parameter Description Value range Access
[current_limit] Max. output current of digital output • 0: 0 A
…
• 2000: 2000mA
…
• 3600: 3600mA
rw
1
