AL4322 Remote I/O module 8DO 8DI
26
9.1.3 Fieldbus: Read the interface configuration
u Observe the notes on the configuration of the EtherNet/IP interface: Configure the EtherNet/IP
interface (Ò/25)
Available parameters:
Name Description Value range Access
[dhcp] Status of the DHCP client of the de-
vice
• Static IP: IP parameters are set by the
user
• DHCP: IP parameters are set by a DHCP
server in the network
• BOOTP: IP parameters are set via the
Bootstrap Protocol
ro
1
[ipaddress] IP address of the EtherNet/IP inter-
face
e.g. 192.100.0.10
192.168.1.250 (default)
ro
1
[subnetmask] Subnet mask of the network seg-
ment
e.g. 255.255.255.0
255.255.255.0 (default)
ro
1
[ipdefaultgateway] IP address of the network gateway e.g. 192.100.0.1
0.0.0.0 (default)
ro
1
[macaddress] MAC address of the Ethernet inter-
face
e.g. 00:02:01:0E:10:7F ro
1
[hostname] Name of the device in the EtherNet/
IP network
e.g. al4x2x ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u Select the [fieldbussetup] > [network] menu.
w The menu page displays the current configuration of the EtherNet/IP interface.
9.1.4 Fieldbus: Reading the connection status
Available information:
Name Description Value range Access
[connectionstatus] Status of the EtherNet/IP connection • Disconnected: Not connected
• Connected: Connected
ro
1
[fieldbusfirmware] Firmware version of the EtherNet/IP
stack
e.g. 3.4.0.7 (EtherNet/IP Adapter) ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u Select the [fieldbussetup] menu.
w The menu page displays the status of the EtherNet/IP connection.
9.1.5 Ports: Configuring input filters
u Observe the notes on input filters: Digital input filters (Ò/9)
Available parameters:
