AL4322 Remote I/O module 8DO 8DI
28
Parameter Description Value range Access
[output_select] Selection of control instance of digital
output
• PLC: higher-level PLC
• Counter 1 SSC Main: switching
channel 1 - main counter
• Counter 1 SSC Batch: switching
channel 1 - batch counter
• Counter 2 SSC Main: switching
channel 2 - main counter
• Counter 2 SSC Batch: switching
channel 2 - batch counter
• Counter 3 SSC Main: switching
channel 3 - main counter
• Counter 3 SSC Batch: switching
channel 3 - batch counter
• Counter 4 SSC Main: switching
channel 4 - main counter
• Counter 4 SSC Batch: switching
channel 4 - batch counter
rw
1
[output_state_com_lost] Fallback value if fieldbus connection is
lost
• State off: OFF
• State on: ON
• Keep last: keep last valid value
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
To configure the outputs of a port:
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u Select menu [io] > [port[n]] > [pin2] (n: 1...4).
w The menu page shows the current settings of the digital output on pin 2 of the port.
u Set the parameters.
u Select menu [io] > [port[n]] > [pin4] (n: 1...4).
w The menu page shows the current settings of the digital output on pin 4 of the port.
u Set the parameters.
u Write the changed values to the device.
w The digital outputs of the device are configured.
9.1.8 Ports: writing the digital outputs
Available parameters:
Parameter Description Value range Access
[digital_output] Signal level of digital output channel • Low: LOW level
• High: HIGH level
rw
1
[qualifier] Status indication of digital output • Output error: error
• Output okay: no error
ro
2
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
2
Read only
To write the digital outputs:
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
