AL4242 Remote I/O module 8DO 8DI
26
Name Description Value range Access
[ipaddress] IP address of the ModbusTCP inter-
face
e.g. 192.100.0.10
• 192.168.1.250 (default)
rw
1
[subnetmask] Subnet mask of the network segment e.g. 255.255.255.0
• 255.255.255.0 (default)
rw
1
[ipdefaultgateway] IP address of the network gateway e.g. 192.100.0.1
• 0.0.0.0 (default)
rw
1
[macaddress] MAC address of the Ethernet inter-
face
e.g. 00:02:01:0E:10:7F ro
2
[hostname] Name of the device in the Mod-
busTCP network
e.g. al4x4x ro
2
1
Read and write
2
Read only
To configure the ModbusTCP interface:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
u Select the [fieldbussetup] > [network] menu.
w The menu page shows the current settings.
u Set IP parameters of the interface.
u Write the changed values to the device.
u Restart the device.
w The ModbusTCP interface is configured
9.1.3.2 Setting ModbusTCP-specific parameters
Changes to the [byteswap] parameters will only take effect after the device has been restarted.
Available parameters:
Name Description Value range Access
[connectiontimeout] Set timeout for interruption of
the fieldbus connection (value
in milliseconds)
• 20: 20 ms
…
• 30000: 30000ms (default)
…
• 60000: 60000 ms
rw
1
[byteswap] Order of the bytes in data
WORD
• 0: Big-Endian (default)
• 65535: Little-Endian
rw
1
1
Read and write
To set the ModbusTCP-specific parameters:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device is established (online).
u Select the [fieldbus] > [configuration] menu.
w The menu page shows the current settings.
u Setting ModbusTCP-specific parameters.
u Write the changed values to the device.
w ModbusTCP-specific parameters are set.
