Remote I/O module 8DO 8DI AL4242
27
9.1.3.3 Reading the connection status
Available information:
Name Description Value range Access
[connectionstatus] Status of the ModbusTCP connection • Disconnected: Not connected
• Connected: Connected
ro
1
[disconnectioncounter] Connection interruption counter • 0: no interruption
…
• 65535: 65535 interruptions
ro
1
[fieldbusfirmware] Firmware version of the ModbusTCP
stack
e.g. 5.4.0.3 (ModbusTCP Server) ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u Select the [fieldbussetup] menu.
w The menu page displays the status of the ModbusTCP connection.
9.1.4 Process connections
The [io] menu provides access to the parameters of the process connections.
9.1.4.1 Configuring the input filters
u Observe the notes on input filters: Digital input filters (Ò/9)
Available parameters:
Name Description Value range Access
[debounce_time] Debounce time (= value * 0.1ms) • 0: 0ms (default)
…
• 500: 50 ms
rw
1
[hold_time] hold time (= value * 0.1ms) • 0: 0ms (default)
…
• 60000: 6000 ms
rw
1
[hold_level] hold level • 0: hold LOW
• 1: hold HIGH (default)
rw
1
[invert] inversion • 0: do not invert (default)
• 1: invert
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
u Select menu [io] > [port[n]] > [pin2] (n: 5...8).
w The menu page shows the available filter parameters for pin 2 of the port.
u Set the parameters.
u Select menu [io] > [port[n]] > [pin4] (n: 5...8).
w The menu page shows the available filter parameters for pin 4 of the port.
u Set the parameters.
u Write the changed values to the device.
w The digital input filters have been configured.
