AL4203 Remote I/O module 8DO 8DI
48
9.2.4.4 Writing the digital outputs
Available data:
Name Description Value range Access
[digital_output] Signal level of digital output channel • Low: LOW level
• High: HIGH level
rw
1
[qualifier] Status of digital output • Output error: error
• Output okay: no error
ro
2
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
2
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select submenu [io] > [port[n]] (n: 1...4).
w The menu page shows the options for controlling the digital outputs on pin 2 and pin 4 of the
port.
u Set the value of the digital outputs.
u Click on to save the changes.
w The set value is provided at the digital output.
u Check whether the status of the digital output is error-free.
9.2.4.5 Reading the switching signal signals
Available data:
Name Description Value range Access
[state] State of the switching signal • False: OFF
• True: ON
ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select submenu [io] > [port[n]] > [ssc] (n: 5...8).
w The menu page shows the current states of the switching signals of the main counter (main) and
the batch counter (batch) of the port.
9.2.4.6 Controlling the switching signal channels
Available data:
Name Description Value range Access
[reset_latch] Reset the switching signal (only ef-
fective if switch point mode = Latch)
• Inactive > Active: Reset switching signal
(INACTIVE)
• otherw.: no action
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select submenu [io] > [port[n]] > [ssc] (n: 5...8).
