Je bekijkt pagina 49 van 82
Remote I/O module 8DO 8DI AL4203
49
w The menu page shows the control signals for the switching channels of the main counter (main)
and the batch counter (batch) of the port.
u Set the status of the switching signals.
u Click on to save the changes.
9.2.4.7 Reading status and diagnostic information
The measuring accuracy of the current and voltage values of the device supply US is ±10%.
Available information:
Name Description Value range Access
[temperature] Device temperature (value in °C) E.g. 52: 52°C ro
1
[voltage_us] Present voltage value of device supply
US (value in mV)
E.g. 25236: 25236mV ro
1
[current_us] Present current value of device supply
US (value in mA)
E.g. 82: 82mA ro
1
[supervisionstatus_us] Status of device supply US • OK: no error
• Fault: error
ro
1
[voltage_ua] Voltage value of device supply UA (value
in mV)
E.g. 25236: 25236mV ro
1
[current_ua_upper] Upper current value of device supply UA
(value in mA)
E.g. 2: 2mA ro
1
[current_ua_lower] Lower current value of device supply UA
(value in mA)
E.g. 82: 82mA ro
1
[supervisionstatus_ua] Status of device supply UA • OK: no error
• Fault: error
ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [processdatamaster] submenu.
w The menu page shows status and diagnostic information.
9.2.4.8 Reading the connection status
Available information:
Name Description Value range Access
[connectionstatus] Status of the connection to the PROFINET net-
work
• disconnected: not connected
• Connected: connected
ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [fieldbussetup] submenu.
w The menu page shows the connection status.
w The menu page shows the number of disconnections.
