Remote I/O module 8DO 8DI AL4203
47
9.2.4.1 Reading digital input data
Available information:
Name Description Value range Access
[digital_input] Process value digital input (after filtering) • Low: LOW
• High: HIGH
ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select submenu [io] > [port[n]] (n: 5...8).
w The menu page shows the digital input data on pin 2 and pin 4 of the port.
9.2.4.2 Reading counter values
Available information:
Name Description Value range Access
[maincounter_value] Current main counter value 0…4294967295 ro
1
[batchcounter_value] Current batch counter value 0…65535 ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select submenu [io] > [port[n]] > [counter] (n: 5...8).
w The menu page shows current counter values of the counter module.
9.2.4.3 Controlling counter modules
Available control signals:
Name Description Values Access
[reset] Reset counter module (reset counter
and threshold values to default values)
• inactive: no action (default)
• active: reset
rw
1
[disable] Disable counter module • inactive: enable counter (default)
• active: disable counter
rw
1
[direction]
2
Set counting direction for main counter
and batch counter
• up: up (default)
• down: down
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
2
only effective if operating mode of counter module = CTDIR
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select submenu [io] > [port[n]] > [counter] (n: 5...8).
w The menu page shows the available services.
u Set the control signals.
u Click on to send the control signals to the device.
w The control signals are executed.
