AL4043 Remote I/O module 16 DI
34
9.2.3.3 Configuring counter modules
u Observe the notes on counter modules: Counter (Ò/10)
If the operating mode of a counter module is changed, the current counter values will be reset
and any active events will be deleted.
For the parameters [pin2_function] and [count_direction_selection] all shown parameter values can be
selected. It is not checked whether these make sense. For each counter operating mode (parameter
[mode]), the table below indicates the valid value ranges (: valid setting; : invalid setting):
[mode]
[pin2_function] [count_direction_selection]
No function
Counting
pulse
Counting di-
rection
Reset main
counter and
batch coun-
ter
Disable main
counter and
batch coun-
ter
Pin 2
IoT Core /
Fieldbus
PLC
CTU
CTD
CTUD
CTDIR
CTDIR
Available parameters:
Name Description Value range Access
[mode] Operating mode of the counter module • CTU (up counter): up counter
(default)
• CTD (down counter): down counter
• CTUD (up counter/ down counter):
up and down counter
• CTDIR (direction counter): up and
down counter with selectable
counting direction
rw
1
[pin2_function]
Pin 2 function of the port (Ò Observe
note!)
• N/C: no function (default)
• Counter edge input 2: counting pulse
(rising edge)
• Count direction: counting direction
• Reset (main & batch counter): reset
main counter and batch counter
• Disable (main & batch counter):
disable main counter and batch
counter
rw
1
[count_direction_selection] Control instance for selecting the count-
ing direction (Ò Observe note!)
• Pin 2 count direction: pin 2 (default)
• IoT / PLC count direction: IoT Core /
Fieldbus PLC
rw
1
[main_threshold] Main counter threshold (CT) • 1
…
• 4294967295 (default)
rw
1
[batch_threshold] Batch counter threshold (CTb) • 1
…
• 65535 (default)
rw
1
1
Read and write; parameter can only be changed if no connection to fieldbus controller is established
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select submenu [io] > [port[n]] > [counter] (n: 1...8).
