Remote I/O module 16 DI AL4043
35
w The menu page shows the current settings.
u Set the parameters.
u Click on to save the changes.
w The counter modules are configured.
9.2.3.4 Setting the arrangement of the digital inputs
The arrangement of the digital input channels in Modbus registers 0, 400 and 401 is adjustable.
Available options:
• Pin-based:
Word
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n X08
pin 2
X07
pin 2
X06
pin 2
X05
pin 2
X04
pin 2
X03
pin 2
X02
pin 2
X01
pin 2
X08
pin 4
X07
pin 4
X06
pin 4
X05
pin 4
X04
pin 4
X03
pin 4
X02
pin 4
X01
pin 4
• Port-based:
Word
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n X08
pin 2
X08
pin 4
X07
pin 2
X07
pin 4
X06
pin 2
X06
pin 4
X05
pin 2
X05
pin 4
X04
pin 2
X04
pin 4
X03
pin 2
X03
pin 4
X02
pin 2
X02
pin 4
X01
pin 2
X01
pin 4
Available parameters:
Name Description Value range Access
[di_channel_mapping] Setting the arrangement of the digital in-
puts in the process data
• 0: Pin-based
• 1: Port-based
rw
1
1
Read and write
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [io] submenu.
w The menu page shows the current settings.
u Set the parameters.
u Click on to save the changes to the device.
w The arrangement of the digital input channels is configured.
9.2.3.5 Reading device information
Available information:
Name Description Value range Access
[productcode] Article number AL4043 ro
1
[vendor] Vendor ifm electronic ro
1
[devicefamily] Device family Ethernet modules ro
1
[serialnumber] Serial number (12 digits) e.g. 000174210161 ro
1
[hwrevision] Hardware revision E.g. AA ro
1
[swrevision] Firmware version E.g. AL4x4x_fw_md_1.4.0.142 ro
1
[bootloaderrevision] Bootloader version E.g. AL4xxx_bl_1.4.0.39 ro
1
