Remote I/O module 16 DI AL4042
37
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [io] > [port[n]] submenu (n: 1...8).
w Menu page shows the digital input data of the port.
9.2.4.2 Reading counter values
Available information:
Name Description Value range Access
[maincounter_value] Current main counter value 0…4294967295 ro
1
[batchcounter_value] Current batch counter value 0…65535 ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [io] > [counter[n]] submenu (n: 1...8).
w The menu page shows current counter values of the counter module.
9.2.4.3 Controlling counter modules
Available control signals:
Name Description Values Access
[reset] Reset counter module (reset counter
and threshold values to default values)
• inactive: no action (default)
• active: reset
rw
1
[disable] Disable counter module • inactive: enable counter (default)
• active: disable counter
rw
1
[direction]
2
Set the counting direction for the main
counter and the batch counter
• up: up (default)
• down: down
rw
1
1
The parameter can only be changed if no connection to the fieldbus controller is active
2
only effective if operating mode of counter module = CTDIR
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [io] > [counter[n]] submenu (n: 1...8).
w The menu page shows available services.
u Set control signals.
u Click on to send the control signals to the device.
w Control signals are executed.
9.2.4.4 Reading status and diagnostic information
Available information:
Name Description Value range Access
[temperature] Temperature of the device (value un de-
grees Celsius)
e.g. 52: 52°C ro
1
