AL4042 Remote I/O module 16 DI
36
ü The [Parameter] menu is active.
u Select the [Devicetag] submenu.
w The menu page shows the current settings.
u Enter the application identifier.
u Click on to save the changes to the device.
w New application identifier is set.
9.2.4 Accessing the process data
The [Processdata] menu page provides access to the process data of the device.
Requirements:
ü IoT Core Visualizer has been started.
u Select the [Processdata] menu.
w The menu page shows the substructures of the device description that contains the process data.
w The current process values are displayed.
u Optional: In the header, activate the [Polling] option and set the polling interval.
w The process values will be refreshed with the set interval.
u Optional: Click on next to an element to manually refresh the process value.
9.2.4.1 Reading digital input data
Available information:
Name Description Value range Access
[pin2] > [digital_input] Process value digital input - pin 2 (after fil-
tering)
• Low: LOW
• High: HIGH
ro
1
[pin4] > [digital_input] Process value digital input - pin 4 (after fil-
tering)
• Low: LOW
• High: HIGH
ro
1
1
Read only
Requirements:
