Remote I/O module 16 DI AL4042
23
Name Description Value range Access
[connectionstatus] Status of the ModbusTCP connection • Disconnected: Not connected
• Connected: Connected
ro
1
[disconnectioncounter] Connection interruption counter • 0: no interruption
…
• 65535: 65535 interruptions
ro
1
[fieldbusfirmware] Firmware version of the ModbusTCP
stack
e.g. 5.4.0.3 (ModbusTCP Server) ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u Select the [fieldbussetup] menu.
w The menu page displays the status of the ModbusTCP connection.
9.1.5 Ports: Setting the arrangement of the digital inputs
The arrangement of the digital input channels in Modbus registers 0, 400 and 401 is adjustable.
Available options:
• Pin-based:
Word
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n X08
pin 2
X07
pin 2
X06
pin 2
X05
pin 2
X04
pin 2
X03
pin 2
X02
pin 2
X01
pin 2
X08
pin 4
X07
pin 4
X06
pin 4
X05
pin 4
X04
pin 4
X03
pin 4
X02
pin 4
X01
pin 4
• Port-based:
Word
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n X08
pin 2
X08
pin 4
X07
pin 2
X07
pin 4
X06
pin 2
X06
pin 4
X05
pin 2
X05
pin 4
X04
pin 2
X04
pin 4
X03
pin 2
X03
pin 4
X02
pin 2
X02
pin 4
X01
pin 2
X01
pin 4
Available parameters:
Name Description Value range Access
[di_channel_mapping] Setting the arrangement of the digital in-
puts in the process data
• 0: Pin-based
• 1: Port-based
rw
1
1
Read and write
To set the arrangement of the digital inputs in the process data:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device has been established.
u Select [io] menu.
w The menu page shows the current settings.
u Set the parameters.
u Write the changed values to the device.
w Arrangement of the digital inputs in the process data is set.
