AL4033 Remote I/O module 16 DI
40
• ADS over EtherCAT (AoE): Using ADS over EtherCAT (AoE) (Ò/40)
9.2.15 Acyclic access
The device supports the following mailbox protocols for acyclic read and write access to the objects in
the object directory:
• Using CANopen over EtherCAT (CoE) (Ò/40)
• Using ADS over EtherCAT (AoE) (Ò/40)
9.2.15.1 Using CANopen over EtherCAT (CoE)
The device supports the mailbox protocol “CANopen over EtherCAT” (CoE). CoE allows acyclic read
or write access to objects on the device.
Only 1 acyclic read/write access can be executed at a time.
Acyclic access options via CoE: Ò user documentation of the projection software
Example: reading the manufacturer ID via CoE
Task: read the manufacturer ID of the device in TwinCAT via CoE
Solution: In TwinCAT via the [CoE – Online] view in [Identity Object] (index: 0x1018), read the value
for [Vendor ID] (subindex: 0x01)
Requirements:
ü The connection to the device is established (online).
u In the [Solution Explorer]: Double-click on the device node.
w A detailed view of the device appears.
u Select the [CoE – Online] tab.
w The object directory of the device appears.
u Select object 0x1018:01 from the table.
w The [Value] column displays the value of the object: 0x00000622 (= ifm electronic)
9.2.15.2 Using ADS over EtherCAT (AoE)
The device supports the ”ADS over EtherCAT” (AoE) protocol. AoE allows uninterrupted acyclic read
and write access to objects on the device.
Multiple acyclic AoE requests can be executed at the same time.
Acyclic access options via AoE: Ò user documentation of the projection software
Specific parameters for device access:
Parameter Description Value range
Port Port number 0x0000FFFF
Index Group AoE index group 0x00003F02
Index Offset Index and subindex of the object
Index Offset:
• bits 16...31: index
• bit 8: complete access (always 0x0)
• bits 0...7: subindex
Index and subindex depend on device, see
Object directory (Ò/46)
