Remote I/O module 16 DI AL4033
39
• Set the output [Reset Main and Batch Counter] of the counter module Controlling counter modules
(Ò/38)
• Set the control signals of the [Reset Counter Event] object of the port Resetting counter events
(Ò/39)
• Change the settings of the counter module Configuring the counter modules (Ò/35)
9.2.12 Resetting counter events
The device provides control signals to reset the overflow and underflow events of the counter
modules. Separate control signals are available for each counter module.
The control signals are accessed via the object area Output area (0x7000 - 0x7FFF) (Ò/56).
Available control signals:
Index Signal Description
0x7018…
0x7088
Reset Main Counter Event Overflow Reset main counter overflow event
Reset Main Counter Event Underflow Reset main counter underflow event
Reset Batch Counter Event Overflow Reset batch counter overflow event
Reset Batch Counter Event Underflow Reset batch counter underflow event
Reset counter events Reset all counter events
Access options:
• CANopen over EtherCAT (EoE): Using CANopen over EtherCAT (CoE) (Ò/40)
• ADS over EtherCAT (AoE): Using ADS over EtherCAT (AoE) (Ò/40)
9.2.13 Reading diagnostic and status information
Diagnostic and status information is provided in the object areas Communication area (0x1000 -
0x1FFF) (Ò/46) and Device area (0xF000 - 0xFFFF) (Ò/60).
Available information:
Index Information Description
0x10F3 Diagnosis History Error messages
0xF110 Power Status Error Error in the device supply (undervoltage, overvoltage, overcurrent,
short circuit, excess temperature)
Access options:
• CANopen over EtherCAT (EoE): Using CANopen over EtherCAT (CoE) (Ò/40)
• ADS over EtherCAT (AoE): Using ADS over EtherCAT (AoE) (Ò/40)
9.2.14 Controlling the device
The device is controlled via the object area Manufacturer-specific area (0x2000 - 0x5FFF) (Ò/52).
Available commands:
Index Command Description
0x2F00 Factory Reset Resets the device to factory settings
0x2F01 Reboot Reboots the device
0x2F02 Device Localization RDY status LEDs flash
Access options:
• CANopen over EtherCAT (EoE): Using CANopen over EtherCAT (CoE) (Ò/40)
