AL4033 Remote I/O module 16 DI
32
u Click on [OK].
w The EoE protocol is activated and configured on the EtherCAT master.
u In the [Solution Explorer]: Select the node of the device.
w The detail window shows device settings.
u Select the [EtherCAT] tab.
w The detail window shows EtherCAT settings.
u Click on [Advanced Settings…].
w A dialogue window appears.
u Select the [Mailbox] > [EOE] menu item.
u Activate the [Virtual Ethernet Port] parameters.
u Activate the [IP Port] parameters.
u Enter IP settings of the device in the Ethernet network.
u Click on [OK].
w The EoE protocol is activated and configured on the EtherCAT slave.
w The device can be reached from the TwinCAT PC via the set IP address.
