Remote I/O module 16 DI AL4033
27
u Optional: In the header, activate the [Polling] option and set the polling interval.
w The process values will be refreshed with the set interval.
u Optional: Click on next to an element to manually refresh the process value.
9.1.4.1 Reading digital input data
Available information:
Name Description Value range Access
[pin2] > [digital_input] Process value digital input - pin 2 (after fil-
tering)
• Low: LOW
• High: HIGH
ro
1
[pin4] > [digital_input] Process value digital input - pin 4 (after fil-
tering)
• Low: LOW
• High: HIGH
ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select the [io] > [port[n]] submenu (n: 1...8).
w Menu page shows the digital input data of the port.
9.1.4.2 Reading counter values
Available information:
Name Description Value range Access
[maincounter_value] Current main counter value 0…4294967295 ro
1
[batchcounter_value] Current batch counter value 0…65535 ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
