AL1591 SolutionBlock IO-Link master
36
Requirements:
ü ifm moneo|configure has been started.
ü The connection to the device is established (online).
ü The parameter setting software has been started.
ü The connection to the device has been established.
w The menu page shows the current settings.
u Set the operating mode.
u Write the changed values to the device.
w Operating mode of pin 2 (UA) of the port has been set.
9.1.5.2 Setting the operating mode Pin 4 (US)
Pin 4 of ports X1...X8 supports the following operating modes:
• Disabled: No data transmission at pin 4 (C/Q) of the port
• Digital input: Binary input signal at pin 4 (C/Q) of the port
• Digital output: Binary output signal at pin 4 (C/Q) of the port
• IO-Link: IO-Link data transmission via pin 4 (C/Q) of the port
The set operating mode must match the operating mode of the device connected to the port (sensor,
actuator, IO-Link device).
Available parameters:
Name Description Value range Access
[Mode Pin4 US] Operating mode of Pin 4 (C/Q) of the
port
• Disabled: Port deactivated
• DI: Digital input
• DO: Digital output
• IO-Link: IO-Link process data
rw
1
1
Read and write
Requirements:
ü ifm moneo|configure has been started.
ü The connection to the device is established (online).
u Select the [Port x] (x = 1…8) menu.
w The menu page shows the current settings.
u Set the operating mode.
u Save the changes on the device.
w Operating mode for pin 4 (C/Q) of the port has been set.
9.1.5.3 Setting the device validation and data storage
Note the remarks: Parameter storage and device validation (Ò/12)
Device validation and backup / restore of parameter values are only available if the “IO-Link”
operating mode of the port has been enabled.
For options [Type compatible V1.1 device with Backup + Restore] and [Type compatible V1.1
device with Restore]: If the [Vendor ID] or [Device ID] parameters are changed in online mode,
the data memory is deleted and a new backup of the parameter values of the connected IO-Link
device is created in the IO-Link master.
Available parameters:
