SolutionBlock IO-Link master AL1591
35
Parameter Description Value range Access
[Independent mode] EtherNet/IP configuration mode • Off: Top-down mode active -- Configuration
via EtherNet/IP PLC
• On: Independent mode active - configuration
via device settings
rw
1
[Process data length] Length of IO-Link process data per
port
• 2 Bytes Input 2 Bytes Output: 2 bytes input
data, 2 bytes output data
• 4 Bytes Input 4 Bytes Output: 4 bytes input
data, 4 bytes output data
• 8 Bytes Input 8 Bytes Output: 8 bytes input
data, 8 bytes output data
• 16 Bytes Input 16 Bytes Output: 16 bytes
input data, 16 bytes output data
• 32 Bytes Input 32 Bytes Output: 32 bytes
input data, 32 bytes output data
rw
1
[Swap] Arrangement of the bytes in process
data
• Disabled: as Array of Bytes
• Enabled: as Integer16 value; When the
process data is updated, the bytes in the
integer16 value are swapped
rw
1
1
Read and write
Requirements:
ü The parameter setting software has been started.
ü The connection to the device is established (online).
ü EtherNet/IP field bus is enabled.
ü The detailed view of the device is active.
u Select the [Fieldbus] menu.
w The menu page shows the current settings.
u Set the parameters.
u Save the changes on the device.
w EtherNet/IP configuration mode is set.
9.1.5 IO-Link ports
The [Port x](x:1...8) menues provide access to the parameters of the IO-Link portsX1...X8.
9.1.5.1 Setting the operating mode pin 2 (UA)
Pin 2 of ports X1...X4 supports the following operating modes:
• Off: Port operates as IO-Link port (class A); Pin 2 is disconnected from the power supply
• On: Port operates as IO-Link port (class B); voltage UA is connected at pin 2;
• Digital output (DO): Port operates as a digital switching output; A binary output signal is available at
pin 2
Available parameters:
Name Description Value range Access
[Mode Pin2 UA] Operating mode of pin 2 (I/Q) of the
port
• Off (IO-Link Type A Supply): IO-Link Port
Class A
• On (IO-Link Type B Supply): IO-Link Port
Class B
• Digital Output: Digital switching output
rw
1
1
Read and write
To set the operating mode of pin 2 (UA) of a port:
