AL1591 SolutionBlock IO-Link master
34
Parameter Description Value range Access
[MAC address] MAC address of the device's PROF-
INET interface
e.g. 00:02:01:0f:c8:8f ro
1
[Fieldbus firmware] Version of the PROFINET firmware E.g. 1.0.0 ro
1
1
Read only
To display the IP configuration of the PROFINET fieldbus interface:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device is established (online).
ü PROFINET is set as the active fieldbus type.
u Select the [Fieldbus] menu.
w The menu page shows the current configuration of the PROFINET interface.
9.1.4.4 Reading the IP configuration of the EtherNet/IP interface
The IP configuration of the Ether/Net-IP interface can only be set via the EtherNet/IP configuration
software.
Available parameters:
Parameter Description Value range Access
[IP address] IP address of the EtherNet/IP interface e.g. 192.168.10.100
• 192.168.1.250 (default)
ro
1
[Subnet mask] Subnet mask of the EtherNet/IP net-
work
e.g. 255.255.255.0
• 255.255.255.0 (default)
ro
1
[Default gateway IP address] IP address of the network gateway e.g. 192.168.10.1
• 0.0.0.0 (default)
ro
1
[Hostname] Host name of the device E.g. iol.plant1 ro
1
[MAC address] MAC address of the device’s EtherNet/
IP interface
e.g. 00:02:01:0f:c8:8f ro
1
[Fieldbus firmware] Version of the EtherNet/IP firmware E.g. 1.1 ro
1
1
Read only
To display the IP configuration of the EtherNet/IP field bus interface:
Requirements:
ü The parameter setting software has been started.
ü The connection to the device is established (online).
ü EtherNet/IP field bus is enabled.
u Select the [Fieldbus] menu.
w The menu page shows the current configuration of the EtherNet/IP interface.
9.1.4.5 Setting the EtherNet/IP configuration mode
The device supports the EtherNet/IP configuration modes Top-Down and Independent. For the
Independent configuration mode, the user must set the length of the process data and the
arrangement of the bytes within the process data.
Available parameters:
