Je bekijkt pagina 33 van 241
SolutionBlock IO-Link master AL1591
33
u Select the [Fieldbus] menu.
w The menu page shows the status of the active fieldbus connection.
9.1.4.2 Setting the fieldbus type
The device can be operated with one of the following fieldbuses:
• PROFINET
• EtherNet/IP
When the fieldbus type is changed, the active fieldbus connection is interrupted.
Available parameters:
Parameter Description Value range Access
[Fieldbus type] Active fieldbus type • Profinet: PROFINET is active
• Ethernet/IP: EtherNet/IP is active
ro
1
1
Read only
To set one fieldbus type:
ü ifm moneo|configure has been started.
ü The connection to the device is established (online).
u Select the [Fieldbus] menu.
w The menu page shows the active fieldbus type.
To activate PROFINET:
u Click on [Switch to Profinet] next to the [Fieldbus type Profinet] field.
w PROFINET field bus is enabled.
w The [Fieldbus type] field shows the change progress.
w After successful modification: A confirmation message appears.
To activate EtherNet/IP:
u Next to [Fieldbus type EtherNetIP] click on [Switch to EtherNetIP] .
w EtherNet/IP field bus is enabled.
w The [Fieldbus type] field shows the change progress.
w After successful modification: A confirmation message appears.
9.1.4.3 Reading the IP configuration of the PROFINET interface
The IP configuration of the PROFINET interface can only be set via the PROFINET configuration
software.
Available parameters:
Parameter Description Value range Access
[IP address] IP address of the PROFINET interface e.g. 192.168.10.100
• 0.0.0.0 (default)
ro
1
[Subnet mask] Subnet mask of the PROFINET network e.g. 255.255.255.0
• 0.0.0.0 (default)
ro
1
[Default gateway IP address] IP address of the network gateway e.g. 192.168.10.1
• 0.0.0.0 (default)
ro
1
[Hostname] Station Name of the device E.g. iol.plant1 ro
1
