AL1327 IO-Link master with EtherNet/IP interface
60
{
"code":"event",
"cid":4711,
"adr":"",
"data":{
"eventno":"6317",
"srcurl":"/timer[1]/counter/datachanged",
"payload":{
"/timer[1]/counter":{"code":200,"data":1},
"/processdatamaster/temperature":{"code":200,"data":39},
"/iolinkmaster/port[2]/iolinkdevice/pdin":{"code":200,"data":"03B0"}
}
}
}
9.2.25.4 Example: Changing a notification
Task: The existing sbscription is to be changed (Ò Example: Subscribing to notifications/59).
Instead of the temperature of the IO-Link master, the operating voltage applied is to be transmitted.
Solution: Overwrite the existing subscription. For this purpose, the parameter values for "cid" and
"callback" in the request must be the same as those of the existing subscription.
• Request:
{
"code":"request",
"cid":4711,
"adr":"/timer[1]/counter/datachanged/subscribe",
"data":{
"callback":"http://192.168.0.4:80/temp",
"datatosend":[
"/iolinkmaster/port[2]/iolinkdevice/pdin",
"/processdatamaster/voltage"]
}
}
9.2.25.5 Example: Subscribing to a notification in CSV format
Task: Every 2 seconds, the current values of the following parameters are to be sent to a network
server with the IP address 192.168.0.4
• Cyclic IO-Link input data of the IO-Link device at port 2
• Operating temperature of the IO-Link master.
The data should be transmitted in CSV format (comma separator).
Solution:
u Use the subscribe service to subscribe to the required data and set the output format to "csv0".
Data in CSV format can only be sent via TCP connection.
• Request:
