IO-Link master with EtherNet/IP interface AL1327
59
Name Description
../subscribe Subscribe to notifications
../unsubscribe Unsubscribe from notifications
../getsubscriptioninfo Display information about notifications
9.2.25.3 Example: Subscribing to notifications
Task: Every 0.5 seconds, the current values of the following parameters are to be sent regularly to a
network server with the IP address 192.168.0.4/temp.
• Cyclic IO-Link input data of the IO-Link device at IO-Link port 2
• Operating temperature of the IO-Link master.
The following options are additionally available:
via WebSockets (ws://): Example: Using WebSockets (Ò/67)
via MQTT (mqtt://): Example: Configure and activate MQTT command channel (Ò/64)
Solution:
u Subscribe to the required data using the subscribe service.
• Request:
{
"code":"request",
"cid":4711,
"adr":"/timer[1]/counter/datachanged/subscribe",
"data":{
"callback":"http://192.168.0.4:80/temp",
"datatosend":[
"/iolinkmaster/port[2]/iolinkdevice/pdin",
"/processdatamaster/temperature"]
}
}
u Set the timer to 500 ms.
• Request:
{
"code":"request",
"cid":4712,
"adr":"/timer[1]/interval/setdata",
"data":{
"newvalue":500
}
}
• Response:
{
"cid":4712,
"code":200
}
• Notification (Format: JSON)
