IO-Link master with EtherNet/IP interface AL1327
61
{
"code":"request",
"cid": 1,
"adr":"/timer[1]/counter/datachanged/subscribe",
"callback":"tcp://192.168.50.59:1883/topic",
"codec":"csv0",
"data":{
"datatosend":[
"/iolinkmaster/port[2]/iolinkdevice/pdin",
"/processdatamaster/temperature"]
}
}
u Set the interval of the timer to 2 seconds:
• Request:
{
"code":"request",
"cid":4712,
"adr":"/timer[1]/interval/setdata",
"data":{"newvalue":2000}
}
The cyclically sent notification has the following structure:
/timer[1]/counter/datachanged,6317,200,1,200,39,200,03B0
9.2.25.6 Example: Unsubscribing from a notification
Task: The existing subscription Example: Subscribing to notifications (Ò/59) is to be deleted.
Solution: Use the unsubscribe service to delete the subscription. For this purpose, the value of the
parameter "callback" in the request must be equal to the value of the existing subscription.
• Request:
{
"code":"request",
"cid":4711,
"adr":"/timer[1]/counter/datachanged/unsubscribe",
"data":{
"callback":"http://192.168.0.4:80/temp"
}
}
9.2.25.7 Example: checking a notification
Task: Display information about the existing subscription Example: Subscribing to notifications
(Ò/59).
Solution: Use the service getsubscriptioninfo and the parameter values cid, "adr" and "callback" of the
existing subscription to retrieve the information.
• Request:
