AL1326 IO-Link master with EtherNet/IP interface
14
6.5.1 Connecting IO-Link devices (class A)
Wiring information:
• The connected IO-Link devices must be supplied exclusively via the IO-Link master.
u Connect the IO-Link devices to ports X01...X08. Maximum cable length per port: 20 m.
u For connection, use M12 connectors (minimum protection rating: IP 65 / IP 66 / IP 67).
u Tighten the cable plug using 1.3 ± 0.1Nm.
6.5.2 Connecting IO-Link devices (Class B)
Wiring information:
• The connection of IO-Link devices (Class B) requires the supply with an additional auxiliary voltage
UA. Feeding is done with the help of a Y-connection cable (Ò accessories).
CAUTION
Non-compliance with the electrical separation of the circuits
w Risk of fire
u Ensure that the external supply UA is electrically separated from the power circuit of the
unit by basic insulation (according to IEC 61010-1, secondary current circuit with max.
30 V DC, derived from mains circuit up to 300 V of overvoltage category II).
u Ensure that the IO-Link devices and the connection technology support the electrical
separation.
• When connecting an IO-Link device (Class B), the additional digital input at pin 2 of the port is not
available.
u Connect IO-Link devices via a Y-connection cable with ports X01...X08.
u Connect Y-connection cable to the supply voltage 24VDC (20…30 V SELV/PELV).
u For connection, use M12 connectors (minimum protection rating: IP 65 / IP 66 / IP 67).
u Tighten the cable plug using 1.3 ± 0.1Nm.
6.6 Ground connection
The FE potential is connected to the following points of the device:
• Upper mounting lug of the housing
To ensure the protection of the device against electrical interference and to ensure the safe
function of the device, the housing has to be connected to the GND of the installation using the
shortest possible route.
u Ground the device via the mounting screw of the upper mounting lug.
6.7 Voltage supply
The device is connected to the US supply voltage via the Power IN port.
The US supply voltage supplies the device and the sensors connected to the ports X01...X08 with
voltage.
Wiring:
