IO-Link master with EtherNet/IP interface AL1326
15
43
2 1
1: +24VDC (US)
2: not used
3: GND (US)
4: not used
u Disconnect power.
u Connect the device via port X31 to 24VDC (20…30V SELV/PELV; according to IEC 61010-1,
secondary circuit with max. 30 V DC, supplied from main circuit up to 300 V of overvoltage
category).
u For connection, use an A-coded M12 connector (minimum protection rating: IP 65 / IP 66 / IP 67).
u Tighten the cable sockets according to the torque specifications indicated by the cable vendor.
Maximum permissible tightening torque: 0.8Nm
Recommended max. cable length: 25 m.
u In case of cables that are longer than 25m, take the voltage drop and the necessary
minimum supply voltage of 20 V into consideration!
Bekijk gratis de handleiding van IFM AL1326, stel vragen en lees de antwoorden op veelvoorkomende problemen, of gebruik onze assistent om sneller informatie in de handleiding te vinden of uitleg te krijgen over specifieke functies.
