IO-Link master with EtherNet/IP interface AL1326
13
u Before connecting the connector, check that there is an undamaged O-ring in the socket.
u Observe the coding of the connectors during installation.
u Cover unused connections with protective covers. Tightening torque: 1.3 ± 0.1Nm
For UL applications:
u To connect the device and the IO-Link devices, only use UL-certified cables belonging to category
CYJV or PVVA with a minimum temperature of 80°C (75°C in case of a maximum ambient
temperature of 40°C).
6.3 Fieldbus ports
The device is connected to the EtherNet/IP network via the Ethernet ports (e.g. EtherNet/IP controller,
additional EtherNet/IP device).
Wiring:
1 2
34
5
1: TX+
2: RX+
3: TX-
4: RX-
5: not used
u Connect the device to the EtherNet/IP network via the X21, X22 ports.
u For connection, use M12 connectors (minimum protection rating: IP 65 / IP 66 / IP 67).
u Tighten the cable plug using 1.3 ± 0.1Nm.
6.4 IoT port
The IoT port connects the device to an IT network (e.g. laptop with configuration tool, monitoring
software or IoT-enabled software).
Wiring:
1 2
34
5
1: TX+
2: RX+
3: TX-
4: RX-
5: not used
u Connect the device to the IT network via port X23.
u For connection, use M12 connectors (minimum protection rating: IP 65 / IP 66 / IP 67).
u Tighten the cable plug using 1.3 ± 0.1Nm.
6.5 IO-Link ports (class A)
IO-Link devices (sensors, actuators) are connected to the IO-Link ports (class B).
The IO-Link ports meet the requirements of the IO-Link specifications 1.0 to 1.1.2.
The ports are equipped with short-circuit detection (US).
The ports have an additional digital input (type 2, according to IEC 61131-2).
Wiring:
3
1 2
4
5
1: Sensor supply (US) L+
2: Digital input
3: Sensor supply (US) L-
4: C/Q IO-Link
5: not used
