AL1325 IO-Link master with EtherNet/IP interface
48
Name Description Value range Access
../datastorage/size Size of the data storage content (in bytes) e.g. 1024: 2 bytes ro
3
1
Read and write
2
The parameter can only be changed if no connection to the fieldbus controller is active
3
Read only
Applicable services:
Name Description
../validation_useconnecteddevice Validate the IO-Link device
../datastorage/getblobdata Reading the content of the data storage area
../datastorage/stream_set Transfer an individual data segment
../datastorage/start_stream_set Start sequential transmission of several data segments
9.2.12.1 Example: Cloning the data memory of an IO-Link port
Task: The data memory of port 2 of IO-Link master 1 is to be cloned to IO-Link master 2.
Solution: The cloning consists of 2 steps. In the first step, the data memory of the port is read by IO-
Link master 1. In the second step, the read data is stored in the data memory of the port of IO-Link
master 2.
Read data memory
u Read segment size of the data storage (h = number of bytes)
{
"code":"request",
"cid": -1,
"adr":"/iolinkmaster/port[2]/datastorage/chunksize/getdata"
}
Example: h = 256
u Read total size of the data storage (g = number of bytes)
{
"code":"request",
"cid":-1,
"adr": "/iolinkmaster/port[2]/datastorage/size/getdata"
}
Example: g = 550
u Calculate the number of reading steps n: n = first integer value for which applies: g < n*h
Example: n= 3, da 550 < 3*256
u Read the data storage segment by segment ("pos" indicates the byte offset at which the read
process starts with the length "length").
