IO-Link master with EtherNet/IP interface AL1325
47
Name Description Value range Access
../mastercycletime_preset Cycle time of the data transfer be-
tween port and IO-Link device (val-
ue in µs); only in IO-Link operating
mode
• 0: Automatically set the best possible cycle
time
• 1: 1 µs
…
• 132800: 132800µs
rw
1
2
1
Read and write
2
The parameter can only be changed if no connection to the fieldbus controller is active
3
Read only
9.2.12 Ports: Configuring device validation and data storage
The device supports the functions device validation and backup / restore of parameter data of the
connected IO-Link devices.
The following options are available:
Option
Validation of the connected
IO-Link device
Backup of parameter values
Restore of parameter val-
ues
[No check and clear] No No No
[Type compatible V1.0 de-
vice]
Yes, test compatibility with IO-
Link standard V1.0
No No
[Type compatible V1.1 de-
vice]
Yes, test compatibility with IO-
Link standard V1.1
No No
[Type compatible V1.1 de-
vice with Backup + Restore]
Yes, test compatibility with IO-
Link standard V1.1 and identity
of design (vendor ID, device
ID)
Yes, automatic backup of pa-
rameter values; Changes to
the current parameter values
will be stored
Yes, restore of parameter val-
ues when connecting an iden-
tical IO-Link device with facto-
ry settings
[Type compatible V1.1 de-
vice with Restore]
Yes, test compatibility with IO-
Link standard V1.1 and identity
of design (vendor ID, device
ID)
No, there is no automatic
backup; Changes to the pa-
rameter values are not stored
Yes, restore of parameter val-
ues when connecting an iden-
tical IO-Link device with facto-
ry settings
Device validation and backup / restore of parameter values are only available if the “IO-Link”
operating mode of the port has been activated.
For options [Type compatible V1.1 device with Backup + Restore] and [Type compatible V1.1
device with Restore]: If the parameters [Vendor ID] or [Device ID] are changed in online mode,
the data memory is deleted and the parameter values of the connected IO-Link device are
backed-up again in the IO-Link master.
Substructure: iolinkmaster/port[x] (x: 1…4)
Available data points:
Name Description Value range Access
../validation_datastor-
age_mode
Behaviour of the port when connecting a
new IO-Link device
• 0: No check and clear
• 1: Type compatible V1.0 device
• 2: Type compatible V1.1 device
• 3: Type compatible V1.1 device
with Backup + Restore
• 4: Type compatible V1.1 device
with Restore
rw
1
2
../validation_vendorid IO-Link ID of the manufacturer that is to be
validated
0…655535 rw
1
2
../validation_deviceid IO-Link ID of the device to be validated 0…16777215 rw
1
2
../datastorage Structure for port data storage - rw
1
2
../datastorage/maxsize Maximum size of the data storage content
(in bytes)
e.g. 2066: 2066 bytes ro
3
../datastorage/chunksize Size of a data segment (in bytes) e.g. 256: 256 bytes ro
3
