AL1325 IO-Link master with EtherNet/IP interface
46
Name Description Value range Access
../swap Swap of the bytes in process data • 0: Off
• 1: On
rw
1
2
1
Read and write
2
The parameter can only be changed if no connection to the fieldbus controller is active
9.2.10 Fieldbus: Setting fail-safe values of the outputs
If the EtherNet/IP connection is interrupted, fail-safe values can be set for the configured outputs of
the ports.
Substructure: fieldbussetup/configuration/port[x] (x:1…4)
Available data points:
Name Description Value range Access
../failsafedigitalout Fail-safe value for the digital output -
pin 4 (DO)
• 0: Failsafe – Reset value
• 1: Failsafe – Old value
• 2: Failsafe – Set value
rw
1
2
../failsafeiolink Fail-safe value for IO-Link output da-
ta - Pin 4 (IO-Link)
• 0: No failsafe
• 1: Failsafe – Reset value
• 2: Failsafe – Old value
• 3: Failsafe with Pattern
rw
1
2
1
Read and write
2
The parameter can only be changed if no connection to the fieldbus controller is active
9.2.11 Ports: Setting the operating mode Pin 4 (US)
Pin 4 of ports X01...X04 supports the following operating modes:
• Disabled: No data transmission at pin 4 (C/Q) of the port
• Digital input: Binary input signal at pin 4 (C/Q) of the port
• Digital output Binary output signal at pin 4 (C/Q) of the port
• IO-Link: IO-Link data transmission via pin 4 (C/Q) of the port
The set operating mode must match the operating mode of the device connected to the port (sensor,
actuator, IO-Link device).
Substructure: iolinkmaster/port[x] (x: 1…4)
Available data points:
Name Description Value range Access
…/mode Operating mode of pin 4 (US) of the
port
• 0: Disabled - port deactivated
• 1: DI - digital input
• 2: DO - digital output
• 3: IO-Link - IO-Link data
rw
1
2
../mastercycletime_actual Current cycle time of the data trans-
fer between port and IO-Link device
(value in µs)
• 0: best possible cycle time
• 1: 1 µs
…
• 132800: 132800 µs
ro
3
../comspeed Current transfer rate between port
and IO-Link device
• 0: COM1 - 4.8 kBaud
• 1: COM2 - 38.4 kBaud
• 2: COM3 - 230.4 kBaud
ro
3
