11-1
BASIC MANUAL
10
11
11
SPECIFICATIONS
D General
• Frequency coverage (unit: MHz):
Receiver 0.030000 ~ 60.000000
Transmitter 0.135700 ~ 0.137800*
1
(Only in the European version)
1.800000 ~ 1.999999*
2
3.500000 ~ 3.999999*
2
5.255000 ~ 5.405000 (Depending on the transceiver version)
7.000000 ~ 7.300000*
2
10.100000 ~ 10.150000
14.000000 ~ 14.350000
18.068000 ~ 18.168000
21.000000 ~ 21.450000
24.890000 ~ 24.990000
28.000000 ~ 29.700000
50.000000 ~ 54.000000*
*
1
Outputs from [X-VERTER].
*
2
The frequency coverage and guaranteed ranges dier, according to the
transceiver version.
• Operating modes:
USB/LSB (J3E), CW (A1A), RTTY (F1B), PSK (G1B), AM (A3E), and FM (F3E)
• Number of memory channels: 101 channels (including 2 scan edges)
• Antenna impedance: 50 Ω unbalanced (When the antenna tuner is OFF)
• Antenna connector: SO-239 (50 Ω) × 4 (for the HF/50 MHz band)
BNC × 1 (for the HF/50 MHz band, RX only)
• Power source requirement:
RF deck 90 ~ 264 V AC (50 Hz/60 Hz)
Controller 15.0 V DC ±0.75 V (Polarity: )
• Operating temperature range: 0°C ~ 50°C, 32°F ~ 122°F
• Frequency stability: ±0.5 ppm or less (0°C ~ 50°C, 32°F ~ 122°F)
• Frequency resolution: 1 Hz
• Power consumption:
Receive Standby 150 VA (typical)
Maximum audio 150 VA (typical)
Transmit Maximum power 800 VA (maximum)
L Includes the controller (Receive Maximum audio: 3 A (maximum, at 15 V DC))
• Dimensions (projections not included):
RF deck 425 (W) × 149 (H) × 442 (D) mm, 16.7 (W) × 5.9 (H) × 17.4 (D) in
Controller 340 (W) × 118 (H) × 103.5 (D) mm, 13.4 (W) × 4.6 (H) × 4.1 (D) in
• Weight (approximate, without the supplied accessories):
RF deck 15.8 kg, 34.8 lb
Controller 2.3 kg, 5.1 lb
D Transmitter
• Transmit output power:
SSB/CW/FM/RTTY/PSK 1 ~ 200 W
AM 0.25 ~ 50 W
• Modulation system:
SSB Digital PSN modulation
FM Digital Reactance modulation
AM Digital Low power modulation
• Spurious emission:
Unwanted emission More than 50 dB (HF band)
More than 66 dB (50 MHz band)
Out-of-band emission More than 40 dB (HF band)
More than 60 dB (50 MHz band)
• Carrier suppression: More than 50 dB
• Unwanted sideband suppression: More than 50 dB
• Microphone impedance: 600 Ω
