11-2
BASIC MANUAL
11
SPECIFICATIONS
D Receiver
• Receive system: RF Direct Sampling Super Heterodyne
• Intermediate frequency: 1st 12 kHz
• Sensitivity:
SSB/CW (BW=2.4 kHz, at 10 dB S/N)
135/475 kHz band +3 dBμV (1.41 μV) typical
1.800000 ~ 29.999999 MHz –16 dBμV (0.16 μV) typical
50 MHz band –18 dBμV (0.13 μV) typical
AM (BW=6 kHz, at 10 dB S/N)
0.500000 ~ 1.799999 MHz +16 dBμV (6.3 μV) typical
1.800000 ~ 29.999999 MHz +6 dBμV (2.0 μV) typical
50 MHz band 0 dBμV (1.0 μV) typical
FM (BW=15 kHz, at 12 dB SINAD)
28.000000 ~ 29.700000 MHz –6 dBμV (0.5 μV) typical
50 MHz band –10 dBμV (0.32 μV) typical
L P.AMP1 is ON in the HF band, and P.AMP2 is ON in the 50 MHz band.
• Sensitivity for the European version (Filter: SOFT):
SSB/CW (BW=2.4 kHz, at 12 dB SINAD)
1.800000 ~ 2.999999 MHz Less than +10 dBμV emf
3.000000 ~ 29.999999 MHz Less than 0 dBμV emf
50 MHz band Less than –6 dBμV emf
AM (BW=4 kHz, 60% Modulation, at 12 dB SINAD)
1.800000 ~ 2.999999 MHz Less than +16 dBμV emf
3.000000 ~ 29.999999 MHz Less than +6 dBμV emf
50 MHz band Less than 0 dBμV emf
FM (BW=7 kHz, 60% Modulation, at 12 dB SINAD)
28.000000 ~ 29.700000 MHz Less than 0 dBμV emf
50 MHz band Less than –6 dBμV emf
L P.AMP1 is ON in the HF band, and P.AMP2 is ON in the 50 MHz band.
• Selectivity (Filter: SHARP):
SSB (BW=2.4 kHz) More than 2.4 kHz/–6 dB
Less than 3.6 kHz/–60 dB
CW (BW=500 Hz) More than 500 Hz/–6 dB
Less than 700 Hz/–60 dB
RTTY (BW=500 Hz) More than 500 Hz/–6 dB
Less than 700 Hz/–60 dB
AM (BW=6 kHz) More than 6.0 kHz/–6 dB
Less than 15.0 kHz/–60 dB
FM (BW=15 kHz) More than 12.0 kHz/–6 dB
Less than 20.0 kHz/–60 dB
• Spurious and image rejection:
SSB/CW/AM/FM
HF band More than 70 dB
50 MHz band More than 70 dB ( except for ADC aliasing:
122.880 MHz – RX frequency)
• Audio output power: More than 2.0 W (8 Ω load, 10% distortion)
• AF output impedance: 8 Ω
• RIT variable range: ±9.999 kHz
• ANF attenuation: More than 30 dB (with 1 kHz single tone)
• NR attenuation: More than 6 dB (noise rejection in SSB)
D Antenna tuner
• Tunable impedance range: 16.7 ~ 150 Ω (unbalanced) (1:3 VSWR or less)
• Tuning accuracy: 1:1.5 VSWR or less
• Tuning time (approximate): 2 ~ 3 seconds (average)
15 seconds (maximum)
L All stated specications are typical and subject to change without notice or obligation.
