Je bekijkt pagina 68 van 100
8-11
BASIC MANUAL
8
SET MODE
Connectors
MENU
»
SET > Connectors > LAN AF/IF Output
Output Select (Default: AF)
Selects the signal output from the [LAN] connector.
• AF: An AF signal is output.
• IF: A 12 kHz IF signal is output.
AF SQL (Default: ON)
Selects whether or not to output the audio from the
[LAN] connector, depending on the squelch state,
when “Output Select” of LAN is set to “AF.”
• OFF (Open): The squelch is always open,
regardless of the transceiver’s
squelch level.
• ON: The squelch opens and closes,
depending on the transceiver’s
squelch level.
MENU
»
SET > Connectors > MOD Input
USB MOD Level (Default: 50%)
LINE-IN MOD Level (Default: 50%)
ACC MOD Level (Default: 50%)
LAN MOD Level (Default: 50%)
Sets the modulation input level of each interface.
DATA OFF MOD (Default: MIC,USB,ACC)
In the SSB, AM, or FM mode, selects the connector(s)
to input the modulation signal when the Data mode is
OFF.
DATA1 MOD (Default: USB)
DATA2 MOD (Default: LINE-IN)
DATA3 MOD (Default: ACC)
In the SSB, AM, or FM mode, selects the connector(s)
to input the modulation signal when the Data mode is
ON.
L Touching the [DATA] key in the MODE screen activates
the Data mode, and automatically sets the modulation
input to the “MIC,” “USB,” “LINE-IN,” “ACC,” “MIC, USB,”
“MIC, LINE-IN,” “MIC, ACC,” “MIC, USB, ACC,” “MIC,
LINE-IN, ACC,” or “LAN” connector(s) selected in these
items, for all three Data modes.
MENU
»
SET > Connectors > USB SEND/Keying
TIP: This is the setting for the terminal used for data
communication when you operate the transceiver
using software on a PC.
The transceiver has 2 virtual COM ports, A and B.
When connecting the [USB B] port on the controller’s
rear panel to your PC, the ports are virtually named
“IC-7760 Serial Port A (CI-V)” and “IC-7760 Serial
Port B.”
USB SEND (Default: OFF)
Sets the USB terminal of the transceiver to receive the
SEND signal from the software on the PC. Select the
same terminal as the terminal set by the software.
L You cannot select the terminal which is already selected
in the “USB Keying (CW)” or “USB Keying (RTTY)” item.
USB Keying (CW) (Default: OFF)
Sets the USB terminal of the transceiver to receive the
CW Keying signal from the software on the PC. Select
the same terminal as the terminal set by the software.
L You cannot select the terminal which is already selected
in the “USB SEND” or “USB Keying (RTTY)” item.
USB Keying (RTTY) (Default: OFF)
Sets the USB terminal of the transceiver to receive
the RTTY Keying signal from the software on the PC.
Select the same terminal as the terminal set by the
software.
L You cannot select the terminal which is already selected
in the “USB SEND” or “USB Keying (CW)” item.
MENU
»
SET > Connectors > External Keypad
VOICE (Default: OFF)
KEYER (Default: OFF)
RTTY (Default: OFF)
PSK (Default: OFF)
Enables each memory (voice, keyer, RTTY, PSK)
transmission using an external keypad.
