8-10
BASIC MANUAL
SET MODE
8
8
MENU
»
SET > Connectors > LINE-OUT AF/IF Output
AF Output Select (Default: MAIN)
Selects the audio signals to output from the
[LINE OUT] jack on the controller’s rear panel in the
Main and Sub bands.
Output Select (Default: AF)
Selects the signal output from the [LINE OUT] jack on
the controller’s rear panel.
• AF: An AF signal is output.
• IF: A 12 kHz IF signal is output.
AF/IF XFC Output (SPLIT ON) (Default: MAIN)
Selects the signal output from the [LINE OUT] jack on
the controller’s rear panel while holding down
XFC
in
split operation.
AF Output Level (Default: 50%)
Sets the AF output level of the [LINE OUT] jack on the
controller’s rear panel, when “Output Select” of LINE-
OUT is set to “AF.”
AF SQL (Default: OFF (Open))
Selects whether or not to output the audio from
the [LINE OUT] jack on the controller’s rear panel,
depending on the squelch state, when “Output Select”
of LINE-OUT is set to “AF.”
• OFF (Open): The squelch is always open,
regardless of the transceiver’s
squelch level.
• ON: The squelch opens and closes,
according to the transceiver’s squelch
level.
AF Beep/Speech... Output (Default: OFF)
Sets the Beep and Speech audio output setting of the
[LINE OUT] jack on the controller’s rear panel, when
“Output Select” of LINE-OUT is set to “AF.”
• OFF: The beep and speech audio are not output.
• ON: The beep and speech audio are output.
IF Output Level (Default: 50%)
Sets the IF output level of the [LINE OUT] jack on the
controller’s rear panel, when “Output Select” of LINE-
OUT is set to “IF.”
MENU
»
SET > Connectors > ACC AF/IF Output
AF/SQL Output Select (Default: MAIN)
Selects the audio and squelch signals to output from
the [ACC 1] socket (Audio: pin 5, Squelch: pin 6) on
the RF deck’s rear panel in the Main and Sub bands.
Output Select (Default: AF)
Selects the signal output from the [ACC 1] socket on
the RF deck’s rear panel.
• AF: An AF signal is output.
• IF: A 12 kHz IF signal is output.
AF/IF XFC Output (SPLIT ON) (Default: MAIN)
Selects the signal output from the [ACC 1] socket on
the RF deck’s rear panel while holding down
XFC
in
split operation.
AF Output Level (Default: 50%)
Sets the AF output level of the [ACC 1] socket on the
RF deck’s rear panel, when “Output Select” of ACC is
set to “AF.”
AF SQL (Default: OFF (Open))
Selects whether or not to output the audio from
the [ACC 1] socket on the RF deck’s rear panel,
depending on the squelch state, when “Output Select”
of ACC is set to “AF.”
• OFF (Open): The squelch is always open,
regardless of the transceiver’s
squelch level.
• ON: The squelch opens and closes,
according to the transceiver’s squelch
level.
AF Beep/Speech... Output (Default: OFF)
Sets the Beep and Speech audio output setting of the
[ACC 1] socket on the RF deck’s rear panel, when
“Output Select” of ACC is set to “AF.”
• OFF: The beep and speech audio are not output.
• ON: The beep and speech audio are output.
IF Output Level (Default: 50%)
Sets the IF output level of the [ACC 1] socket on the
RF deck’s rear panel, when “Output Select” of ACC is
set to “IF.”
