8-7
BASIC MANUAL
8
SET MODE
Function
MENU
»
SET > Function > MIC Key Customize
[UP] (Default: UP (VFO: kHz))
[DN] (Default: DOWN (VFO: kHz))
The function assignments for the [UP] and [DN] keys
on the SM-50 or HM-219 optional microphone can be
changed.
L See page 8-8 about the functions.
MENU
»
SET > Function
Screen Keyboard Type (Default: Full Keyboard)
Sets the keyboard entry type to Ten-Key or Full
Keyboard.
Screen Full Keyboard Layout (Default: English)
Sets the on-screen keyboard layout to English,
German, or French.
Screen Capture [POWER] Switch (Default: OFF)
Assigns the Screen Capture function to
POWER
.
• OFF:
POWER
does not act as the Screen Capture
key.
• ON:
POWER
acts as the Screen Capture key.
Screen Capture Keyboard [Print Screen]
(Default: OFF)
Assigns the Screen Capture function to the [Print
Screen] key on the USB keyboard.
Screen Capture Storage Media (Default: SD Card)
Selects the SD card or USB ash drive to save screen
capture data.
Screen Capture File Type (Default: PNG)
Sets the le format for the Screen Capture function to
PNG or BMP.
Calibration Marker (Default: OFF)
Turns the reference frequency calibration marker ON
or OFF.
REF Adjust
Adjusts the internal reference frequency.
NOTE: The default setting of “REF Adjust” may dier
slightly, depending on each transceiver.
The assignable key functions for Front Key:
Function Description
VOX/BK-IN*
Push to turn the VOX function in the Voice
operation modes and the Break-in function
in the CW mode ON or OFF.
L This function can be assigned for only
VOX/BK-IN
.
AUTOTUNE
In the AM or CW mode
Push to automatically tune the operating
frequency to a close-by signal.
L This function can be assigned for only
AUTO
TUNE
.
PRESET Push to open the PRESET screen.
Voice/Keyer/
RTTY/PSK
Memory 1
In the SSB, AM, or FM mode
• Push to transmit the voice audio
recorded on the SD card once.
• Hold down for 1 second to repeatedly
transmit the voice audio.
LIf the voice audio is not saved in the Voice TX
memory (T1 ~ T4), this function is disabled.
In the CW mode
• Push to transmit the Keyer memory
content once.
• Hold down for 1 second to repeatedly
transmit the memory content.
LIf the Keyer memory content (M1 ~ M4) is not
entered, this function is disabled.
In the RTTY mode
Push to transmit the RTTY memory
content once.
LIf the RTTY memory content (RT1 ~ RT4) is
not entered, this function is disabled.
In the PSK mode
Push to transmit the PSK memory content
once.
LIf the PSK memory content (PT1 ~ PT4) is
not entered, this function is disabled.
Voice/Keyer/
RTTY/PSK
Memory 2
Voice/Keyer/
RTTY/PSK
Memory 3
Voice/Keyer/
RTTY/PSK
Memory 4
* Hold down for 1 second to open its function menu.
NOTE: When you assign other than “VOX/BK-IN”
(default) to
VOX/BK-IN
, the indicator on
VOX/BK-IN
does not light even if you turn ON the VOX or
Break-in function.
