8-5
BASIC MANUAL
8
SET MODE
Function
MENU
»
SET > Function > SPLIT
SPLIT LOCK (Default: OFF)
Turns the Split Lock function ON or OFF.
The SPLIT LOCK function enables you to adjust the
transmit frequency while holding down
XFC
, even
while the Dial Lock function is activated. To prevent
accidentally changing the receive frequency by
rotating
MAIN
DIAL
, use both the SPLIT LOCK and Dial
Lock functions (p. 3-9).
• OFF: Turns OFF the function.
• ON: Turns ON the function.
MENU
»
SET > Function > Tuner
PTT Start (Default: OFF)
Turns the PTT Start Tuning function ON or OFF.
This function starts tuning when [PTT] is pushed, if the
operating frequency is shifted 1% or more while the
antenna tuner is ON.
<<Preset Memory Clear>>
Clears all of the internal antenna tuner’s entered
memory frequencies.
Select the antenna to clear the memory between “ANT
1,” “ANT 2,” “ANT 3,” “ANT 4,” and “All.”
L To clear all antenna memories, select “All.”
MENU
»
SET > Function
Transverter Function (Default: Auto)
Selects whether to turn ON the transverter function
or to automatically turn it ON when 2 to 15 V DC is
applied to pin 6 of [ACC 2].
Transverter Oset (Default: 16.000 MHz)
Sets the oset frequency for transverter operation.
IC-PW2 Dual Connection Mode (Default: OFF)
Synchronizes the operating frequency and band when
the transceiver is connected to the IC-PW2’s RF input
connectors ([INPUT 1] and [INPUT 2]).
• OFF: Not synchronized with the IC-PW2.
• ON: Synchronized with the IC-PW2.
L When the IC-PW2 is not connected to the transceiver, BE
SURE to select “OFF.” Otherwise, you cannot use some
functions, such as antenna switching.
RTTY Mark Frequency (Default: 2125)
Selects the RTTY mark frequency.
L When the internal RTTY decoder is used, 2125 Hz is
automatically selected.
RTTY Shift Width (Default: 170)
Selects the RTTY shift width.
L When the internal RTTY decoder is used, 170 Hz is
automatically selected.
RTTY Keying Polarity (Default: Normal)
Selects the RTTY keying polarity.
• Normal: Key open/close = Mark/Space
• Reverse: Key open/close = Space/Mark
PSK Tone Frequency (Default: 1500)
Selects the PSK tone frequency for PSK reception.
MENU
»
SET > Function > SPEECH
SPEECH Language (Default: English)
Sets the speech language to English or Japanese.
SPEECH Speed (Default: Fast)
Sets the speech speed to Fast or Slow.
S-Level SPEECH (Default: ON)
Turns the S-meter level announcement ON or OFF.
• OFF:
The operating mode and the operating
frequency are announced when you push
SPEECH
.
• ON: The signal strength level, the operating mode,
and the operating frequency are announced
when you push
SPEECH
.
MODE SPEECH (Default: OFF)
Turns the operating mode announcement ON or OFF.
• OFF:
The selected operating mode is not announced.
• ON: The selected operating mode is announced.
SPEECH Level (Default: 50%)
Sets the Voice Synthesizer audio output level.
