8-4
BASIC MANUAL
SET MODE
8
8
RF/SQL Control (Default: RF+SQL)
Set the AF RF/SQL (outer) control operation.
L See the Advanced manual for details.
Cancel CI-V Remote Set Levels
(Default: All Volume Levels)
While remotely controlling the transceiver, sent CI-V
commands override some of the control dials’ setting
values.
Select whether or not to overwrite all control dial’s
setting values (such as the AF Volume dial with a
mark on it) by their position if one of them on the
transceiver is rotated.
• All Volume Levels:
All dials’ setting values are overwritten by their
position, even if one of them is rotated.
• Operated Volume Level:
Only the rotated dial’s setting value is
overwritten by its position.
MENU
»
SET > Function > TX Power Limit
1.8M (Default: 200W (AM: 50W))
1.8M (DATA) (Default: 200W (AM: 50W))
3.5M (Default: 200W (AM: 50W))
3.5M (DATA) (Default: 200W (AM: 50W))
5M (Default: 200W (AM: 50W))
5M (DATA) (Default: 200W (AM: 50W))
7M (Default: 200W (AM: 50W))
7M (DATA) (Default: 200W (AM: 50W))
10M (Default: 200W (AM: 50W))
10M (DATA) (Default: 200W (AM: 50W))
14M (Default: 200W (AM: 50W))
14M (DATA) (Default: 200W (AM: 50W))
18M (Default: 200W (AM: 50W))
18M (DATA) (Default: 200W (AM: 50W))
21M (Default: 200W (AM: 50W))
21M (DATA) (Default: 200W (AM: 50W))
24M (Default: 200W (AM: 50W))
24M (DATA) (Default: 200W (AM: 50W))
28M (Default: 200W (AM: 50W))
28M (DATA) (Default: 200W (AM: 50W))
50M (Default: 200W (AM: 50W))
50M (DATA) (Default: 200W (AM: 50W))
Sets the power limit to between 2 W and 200 W for
each selected band.
L The maximum output power from an antenna connector
to which the AH-730 optional antenna tuner is connected
is limited to 100 W.
MENU
»
SET > Function > TX Delay
HF (Default: OFF)
50M (Default: OFF)
Sets the TX delay time on each band.
L If an external equipment’s rise time is slower than that
of the IC-7760, a reected wave is produced, and it may
damage the IC-7760 or the external device. To prevent
this, set the appropriate delay time so that no reected
wave or timing damage occurs.
L Select “OFF” for no delay.
SEND
Po
Rx
Tx
0 10
Delay time (ms)
MENU
»
SET > Function
Time-Out Timer (CI-V) (Default: OFF)
Sets the Time-out Timer for CI-V operation to OFF,
3, 5, 10, 20, or 30 minutes to prevent an accidental
prolonged transmission.
This setting is valid only for transmitting initiated by a
CI-V command or pushing
TRANSMIT
.
L Select “OFF” for no time limit.
Quick Dualwatch (Default: ON)
Turns the Quick Dualwatch function ON or OFF by
holding down
DUAL-W
for 1 second.
MENU
»
SET > Function > SPLIT
Quick SPLIT (Default: ON)
Turns the Quick SPLIT function ON or OFF.
This function automatically turns ON the SPLIT
function, and sets the frequency and mode according
to the SPLIT Oset setting.
• OFF: Turns OFF the function.
• ON: Turns ON the function.
Display Keypad on Quick SPLIT (Default: OFF)
In the SSB, CW, RTTY, PSK, or AM mode, selects
whether or not to display the F-INP screen by holding
down
SPLIT
for 1 second.
FM SPLIT Oset (HF) (Default: –0.100 MHz)
FM SPLIT Oset (50M) (Default: –0.500 MHz)
In the FM mode, sets the SPLIT oset between
–9.999 and +9.999 MHz.
The SPLIT oset is the dierence between the receive
and transmit frequencies for the Quick SPLIT function.
