8-3
BASIC MANUAL
8
SET MODE
CW-KEY Set
Paddle Polarity (Default: Normal)
Sets the paddle dot-dash polarity to Normal or
Reverse.
• Normal: Right = dash, Left = dot
• Reverse: Right = dot, Left = dash
Key Type (Default: Paddle)
Sets the key type for the [ELEC-KEY] jack on the
controller’s rear panel.
• Set to Straight, Bug, or Paddle.
L When using an external Elec-keyer, select “Straight.”
MIC Up/Down Keyer (Default: OFF)
Selects whether or not to use the keys on the
microphone as a CW key.
• OFF: Do not use the microphone keys as a CW key.
• ON: Use the [UP]/[DN] keys as a CW key.
L The microphone keys do not work as a “squeeze key.”
L When “ON” is selected, you cannot use the function that
is assigned to each key.
Function
MENU
»
SET > Function
Beep Level (Default: 50%)
Sets the beep output level.
L If “Beep (Conrmation)” is set to “OFF,” no beeps sound.
Beep Level Limit (Default: ON)
Selects whether or not to limit the volume up to a
specied level.
• OFF: Does not limit the volume level.
• ON: Limits the volume level.
Beep (Conrmation) (Default: ON)
Turns the Conrmation beep ON or OFF.
• OFF: Turns OFF the function for silent operation.
• ON: A beep sounds when a switch is pushed or
the touch panel is touched.
L If “Beep Level” is set to “0%,” no beep sounds.
Band Edge Beep (Default: ON (Default))
Selects an option for the Band Edge Beep function.
• OFF: Turns OFF the function.
• ON (Default): A beep sounds when you tune out
of, or back into the default amateur
band’s frequency range.
• ON (User): A beep sounds when you tune out
of, or back into a user programmed
amateur band’s frequency range.
• ON (User) & TX Limit:
A beep sounds when you tune out
of, or back into a user programmed
amateur band’s frequency range.
Transmitting is inhibited outside of the
range.
L If “Beep Level” is set to “0%,” no beep sounds.
Beep Sound (MAIN) (Default: 1000Hz)
Beep Sound (SUB) (Default: 1000Hz)
Sets the audio frequency for beeps to between 500
and 2000 Hz.
Speaker MAIN/SUB Mix (Default: OFF)
Sets the audio output from the internal and external
speaker.
• OFF:
Outputs the Main band’s audio from the left side,
and the Sub band’s audio from the right side.
• ON: Outputs the mixed audio.
L See page 13-7 for details.
