8-2
BASIC MANUAL
SET MODE
8
8
Tone Control/TBW
MENU
»
SET > Tone Control/TBW > RX
SSB, AM, FM, CW, RTTY, PSK
RX HPF/LPF (Default: – – – – – – – – –)
Sets the cut-o frequencies for the receive audio high-
pass lter and low-pass lter, in 100 Hz steps.
L If this item is set, the “RX Bass” and “RX Treble” items
are automatically set to “0.”
L In the Data mode, the Tone Control settings are
automatically disabled.
SSB, AM, FM
RX Bass (Default: 0)
RX Treble (Default: 0)
Sets the bass or treble level of the receive audio.
L In the Data mode, the Tone Control settings are
automatically disabled.
MENU
»
SET > Tone Control/TBW > TX
SSB, AM, FM
TX Bass (Default: 0)
TX Treble (Default: 0)
Sets the bass or treble level of the transmit audio.
SSB
TBW (WIDE) (Default: 100 – 2900)
TBW (MID) (Default: 300 – 2700)
TBW (NAR) (Default: 500 – 2500)
Sets the transmission passband width to wide, mid,
or narrow, by changing the lower and upper cut-o
frequencies.
SSB-D
TBW (Default: 300 – 2700)
Sets the transmission passband width by changing
the lower and upper cut-o frequencies.
NOTE: The default settings shown below are for the
USA transceiver version. The default settings may
dier, depending on your transceiver version.
CW-KEY Set
L You can also set the same items in the CW-KEY SET
menu on the KEYER screen. (p. 4-13)
MENU
»
SET > CW-KEY Set
Side Tone Level (Default: 50%)
Adjusts the CW side tone output level.
• Adjust to between 0 ~ 100%.
Side Tone Level Limit (Default: ON)
Turns the CW side tone level limit ON or OFF. This
function disables the CW side tone when you increase
AF GAIN above the side tone level.
Keyer Repeat Time (Default: 2sec)
Sets the time between Memory keyer transmissions.
• Set to between 1 ~ 60 seconds.
L After transmitting a Memory keyer contents, the
transmission is repeated after the set time period.
L
is displayed, even between transmissions.
Dot/Dash Ratio (Default: 1:1:3.0)
Sets the dot/dash ratio.
• Set to between 1:1:2.8 ~ 1:1:4.5 in 0.1 steps.
Keying weight example: Morse code “K”
1 1 3
1 1 2.8～4.5
Default: 1:1:3
Setting range
1:1:2.8 to 1:1:4.5
Setting range Space
Dot Dash Dash
Rise Time (Default: 4ms)
Sets the rise time of the transmitted CW envelope.
• Set to 2, 4, 6, or 8 milliseconds.
TX
RX
0
Key action
TX output
power
Rise time
Set TX output power
Time
