6-1
BASIC MANUAL
6
SD CARD/USB FLASH DRIVE
The SD cards, SDHC cards, and USB ash drive are
user supplied.
TIP: Icom recommends that you save the
transceiver’s factory default data for backup.
About the SD cards
You can use an SD card of up to 2 GB, an SDHC of
up to 32 GB, or an SDXC of up to 256 GB. Icom has
checked the compatibility of the following cards.
(As of August 2025)
Brand Type Capacity
SanDisk
®
SD 2 GB
SDHC 4/8/16/32 GB
SDXC 64/128/256 GB
L The above list does not guarantee the card’s
performance.
L Throughout the rest of this document, the SD cards,
SDHC cards, and SDXC cards are simply called the SD
card or the card.
About the USB ash drive
Use the USB ash drive that supports the interface
1.1 or 2.0.
L These do not guarantee the USB ash drive’s
performance.
L Throughout the rest of this document, the USB ash
drives are called the USB ash drive or the ash drive.
NOTE:
• Before using the SD card or USB ash drive, thoroughly
read their instructions.
• If any of the following occur, the card’s or ash drive’s
data may be corrupted or deleted.
- You remove the card or ash drive from the
transceiver while it is still accessing the card.
- A power failure occurs, or the power cable is
disconnected, while accessing the card.
- You drop, impact, or vibrate the card or ash drive.
• DO NOT touch the contacts of the card or ash drive.
• The transceiver may take a longer time to recognize a
high capacity card or ash drive.
• The card or ash drive has a certain lifetime, so data
reading or writing may not be possible after using it for
a long period of time. In that case, use a new one. We
recommend that you make a backup of the data onto
another device.
• Icom will not be responsible for any damage caused by
data corruption on a card or ash drive.
• If you transfer or dispose of your SD card or USB ash
drive, rst completely delete its data to avoid leaking.
NOTE:
Before using an SD card or USB ash drive for
the rst time, format it in the transceiver.
• Formatting a card or ash drive erases all its data.
Before formatting any used card or ash drive, back up
its data onto another device.
• After inserting or formatting, a special folder on the card
or ash drive that you need for operations like updating
the rmware is created on the card or ash drive.
IMPORTANT: Even if you have formatted an SD
card or ash drive, some data may remain in it.
When you dispose the card or ash drive, be sure to
physically destroy it to avoid unauthorized access to
any data that remains.
Beveled corner
Saving data
You can save the following data onto the card or USB
ash drive.
SD Card
• The transceiver’s settings
• Communication/receive log and contents
• Voice audio for the Voice TX function
• RTTY and PSK decode log
• Captured screens
USB ash drive
• The transceiver’s settings
• Captured screens
Inserting
Insert the SD card or USB ash drive as shown below.
L Insert the SD card into the slot until it locks in place, and
makes a ‘click’ sound.
L Be sure to check the card or ash drive orientation before
inserting.
LOCK
SD
Controller
(front panel)
Lights blue
Controller (rear panel)
SD card
USB ash drive
• is displayed on
the screen.
