BASIC MANUAL
PANEL DESCRIPTION
1
1
Touch screen display (Sub screen)
You can display one of the following screens on the
Sub screen for your convenience.
• Filter Eect screen
• Keypad screen
• Meter screen
z Push
SUB DISP
to select the screen.
D Meter screen
Displays the meter indicator of the Main band.
L When the Split function is ON, displays the meter
indicator of the Sub band.
L To select the displayed parameter, touch the meter.
L To change the displayed meter type, touch the meter for
1 second.
D Keypad screen
You can select the operating band by pushing once,
or call up other stacked frequencies by pushing the
same key several times.
L The Band Stacking Register provides 3 memories for
each band key to store frequencies and operating modes.
To display the Band Stacking Register contents, touch the
band key for 1 second.
L To directly enter the frequency using the Tenkey pad,
touch [F-INP].
D Filter Eect screen
Displays the received signals and the lter passband
width. You can check the lter (Digital Twin PBT, IF
lter, or Notch Filter) removes the signals that are out
of the passband.
L When using the Dualwatch or Split function, displays only
the selected band (Main/Sub).
1Main/Sub band icon
2Passband width
3Shift value
4FFT scope zone
(FFT: Fast Fourier Transform)
5Waterfall zone
6Edge (Upper frequency)
7Passband center frequency
8Edge (Lower frequency)
9Passband
SUB DISP
1 2
4
3
5
6789
Band keypad Tenkey pad
Normal Multi-function meter
