8 Electrical system
120 Exsis I/T - 01/23-1 - EHG-0027-02EN
The transformer/rectifier only works in conjunction with a panel.
The current available at the transformer/rectifier (18 A maximum) is divided
into charging current and current for the appliances. The charging current is
always just the portion that is not being used by any appliances. If the cur-
rent to the appliances exceeds the current available, then the living area bat-
tery is discharged.
The transformer/rectifier is fitted under the L-seating group and can be ac-
cessed by an external flap.
8.6.1 Battery cut-off switch
The battery cut-off switch switches off all the appliances in the living area,
even inactive ones. In the process, all appliances supplied by the trans-
former/rectifier are disconnected from the living area battery. Even appli-
ances such as the entrance step, basic lighting or the refrigerator will stop
working. This prevents the living area battery from slowly discharging if the
vehicle is not used for a longer period of time (e.g. temporary lay-up).
The battery cut-off switch is located on the transformer/rectifier.
If the vehicle is connected to the 230 V power supply via the CEE socket
outlet, the batteries are charged, even if the battery cut-off switch is
switched off.
8.6.2 Battery selector switch
If the battery selector switch is set incorrectly, there is a risk of gener-
ating oxyhydrogen gas. Danger of explosion!
Incorrect setting of the battery selector switch damages the living area
battery.
The factory settings of the battery selector switch must not be changed.
The battery selector switch is located on the transformer/rectifier.
Position
Position
Position
