6 Living
108 B-MC I/T - 01/23-1 - EHG-0016-03EN
6.13.4 Queen size bed in the rear, mechanically height-adjustable
Lower the bed to its lowest position to sleep in it.
Before using the bed, make sure that the lever of the locking device
(Fig. 109,2) is in the locked position (horizontal).
The height of the fixed bed can be adjusted via a crank in the rear garage.
The bed can be raised before setting off. This increases the storage space
under the bed.
Fig. 108 Queen size bed (example)
Fig. 109 Crank in the rear garage
◼ Plug crank (Fig. 109,1) onto the journal of the drive.
◼ Swivel the lever (Fig. 109,2) downwards into vertical position.
◼ To lift the bed: Turn the crank (Fig. 109,1) clockwise.
◼ To lower the bed: Turn crank (Fig. 109,1) in an anticlockwise direction.
◼ Swivel the lever (Fig. 109,2) upwards into horizontal position.
◼ Remove the crank and store it.
When the bed has been lifted to the uppermost position, a hinged panel al-
lows the use of the rear garage.
Hinged panel
