Living 6
B-MC I/T - 01/23-1 - EHG-0016-03EN 107
Fig. 106 Pull-down bed complete with
applied safety net
Fig. 107 Pull-down bed, completely lo-
wered (dependent on model)
The safety nets (Fig. 106,2) with their retaining belts are located underneath
the mattress in the pull-down bed. Only use the safety nets if persons are
already in the pull-down bed.
If the pull-down bed is lowered below 1 m (Fig. 107), it will not be pos-
sible to set up the safety nets.
◼ Attach retaining belts (Fig. 106,1) to the hooks on the ceiling.
If the pull-down bed is raised over 1 m, only access the pull-down bed using
the access ladder provided.
◼ Hook both bows (Fig. 106,4) of the access ladder (Fig. 106,5) into the
holders (Fig. 106,3).
◼ Release the access ladder (Fig. 106,5) from the holders (Fig. 106,3).
◼ Store the access ladder securely.
If it is no longer possible to move the pull-down bed electrically, first check
the fuse 25 A for the motor (on the transformer/rectifier) and the fuse 2 A for
the control (F3, next to the transformer/rectifier). If the fuses are okay, but it
is still not possible to move the pull-down bed, the pull-down bed can be
operated manually with a crank.
Depending on the model, the motor of the pull-down bed may be instal-
led behind a panel or inside one of the wall-mounted cupboards.
◼ If present, pull lid off to obtain access to the mount for the crank.
◼ If the motor is installed into the wall-mounted cupboard: Open the wall-
mounted cupboard on the left.
◼ Take mattress off from the pull-down bed and reduce the load of the
possibly attached storage cupboards as far as possible.
◼ Insert the crank provided or an Allen wrench into the accommodation on
the motor.
◼ Turn crank or Allen wrench manually until the pull-down bed has
reached the upper parking position.
◼ Contact customer service.
Safety net
Setting up:
Access ladder
Attaching:
Storing away:
Emergency operation
