20
Installation
B. Connect to Fish Finder
CAUTION
This NMEA 2000 Direct Cable is NOT intended for use with a NMEA 2000
backbone. It should ONLY be used with the AS GPS HS N2K and a compatible
Humminbird fish finder. The input voltage for the SAE power cable is a nominal
marine vessel voltage of 12 V DC.
Use the following instructions to connect the Sensor directly to the fish finder.
The Sensor requires an external power source, which is connected using the
included NMEA 2000 direct cable and the SAE power cable.
1. Insert the Sensor’s NMEA 2000 Cable into the NMEA 2000 Direct Cable.
The connectors are keyed to prevent reversed installation, so be careful
not to force the connector into the port.
2. Connect the NMEA 2000 connector on the Direct Cable to the NMEA
2000 port on the fish finder. The connectors are keyed to prevent reversed
installation, so be careful not to force the connector into the port.
NOTE
To connect to a HELIX G4N, you must use an additional adapter cable. Connect the
NMEA 2000 connector on the Direct Cable to the AS QD NMEA 2000 adapter cable
(not included). Connect the other end of the AS QD NMEA 2000 adapter cable to
the NMEA 2000 port on the HELIX G4N.
3. Connect the SAE connector on the NMEA 2000 Direct Cable to the SAE
Power cable.
NOTE
This step is not necessary if you are connecting the Sensor to a Humminbird ICE
unit. The Humminbird ICE unit already has an SAE Power Cable connected to the
battery. Connect the SAE connector on the Direct Cable to one of the open SAE
ports on the ICE unit.
4. Power: Route the SAE power cable to the main switch or fuse panel
(usually located near the console), or connect to a battery switch
(not included).
