Heat sink with fan
To remove the heat sink with fan, use these procedures.
Table 4-10
Heat sink with fan description and part number
Description Spare part number
Heat sink with fan P29814-001
IMPORTANT: The bond between the heat sink and the processor can be very tight.
If the computer will turn on, before removing the heat sink, turn on the computer until it warms the heat
sink. Warming the heat sink loosens the bond between the heat sink and the processor, thereby making
it easier to separate them.
Do not pull the processor out of the socket when you lift the heat sink, especially if you cannot warm
the heat sink before removal. Inadvertently removing the processor can damage the pins.
Before removing the heat sink with fan, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 19).
2. Remove the access panel (see Access panel on page 19).
3. (UMA models only) Remove the fan duct (see Fan duct (UMA models only) on page 22).
Remove the heat sink with fan:
1. Disconnect the fan cable from the system board connector (1).
Heat sink with fan
35
