Remove the two Phillips screws (1) that secure the board to the computer, and then lift the board (2) to
disconnect it from the connector on the system board.
To install the flex I/O connector board, reverse the removal procedure.
Heat sink
To remove the heat sink, use these procedures.
Table 4-11
Heat sink descriptions and part numbers
Description Spare part number
For use in 65 W models M23829-001
For use in 35 W models M23830-001
IMPORTANT: The bond between the heat sink and the processor can be very tight.
If the computer will turn on, before removing the heat sink, turn on the computer until it warms the heat
sink. Warming the heat sink loosens the bond between the heat sink and the processor, thereby making
it easier to separate them.
Make sure not to pull the processor out of the socket when you lift the heat sink, especially if you
cannot warm the heat sink before removal. Inadvertently removing the processor can damage the pins.
Before removing the heat sink, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 19).
2. Remove the access panel (see Access panel on page 19).
3. Remove the fan (see Fan on page 24).
Remove the heat sink:
1. In the order indicated on the heat sink, loosen the three captive Torx screws (1).
Heat sink
35
